Description
The CSEB 5L-A1-E battery pack supports a 1C discharge rating, delivering stable power for critical loads and high-demand applications. Its modular design allows easy installation and scalability, supporting expansion up to 15 units to meet higher energy storage requirements.Built with durability in mind, this low-voltage battery pack maintains reliable operation even under challenging environmental conditions. It features an IP20 protection rating, wide operating temperature range, and a cycle life exceeding 6000 cycles @25°C, ensuring consistent and efficient power output for years.
Key Features:
- Built-in Intelligent BMS: Ensures advanced protection and efficient battery management for longer lifespan.
- Easy Installation & Scalability: Compact design allows quick setup and effortless capacity expansion up to 15 units.
- High Operational Reliability: Stable performance with consistent power delivery for residential and commercial backup systems.
- >97% Depth of Discharge (DOD): Maximizes usable energy for extended operation and efficiency.
- 1C Rating for Critical Loads: Provides strong and stable current output to support high-demand applications.
| Feature | Value |
|---|---|
| Model | CSEB-5L-A1-E |
| Product Type | Low Voltage Battery Pack |
| Nominal Voltage (VDC) | 51.2 |
| Nominal Capacity (kWh) | 5.12 |
| Usable Capacity (kWh) | 5 |
| Charge/Discharge Current (A) | 100A, 1C |
| Cycle Life (@25°C) | ≥6000 |
| Communication Port | CAN |
| Expansion | Up to 15 units |
| IP Rating | IP20 |
| Dimension (W×D×H mm) | 460 × 510 × 153 |
| Weight (kg) | 47.5 |
| Working Temperature (°C) – Charge | 0 ～ 55 |
| Working Temperature (°C) – Discharge | -20 ～ 60 |
| Storage Temperature (°C) | -10 ～ 35 |
| Humidity (RH) | 0% ～ 95% |
| Altitude (m) | ≤4000 |
