Description
With support for high-voltage PV input up to 500V, fast transfer time, and multiple communication options including WiFi, the PV5600 is ideal for modern solar installations requiring efficiency, flexibility, and smart monitoring.
Key Features
5600W Solar Capacity – Supports up to 5600W PV array for maximum solar utilization
Dual MPPT Solar Charger – Improves energy harvesting efficiency from solar panels
Pure Sine Wave Output – Safe and stable power for sensitive electronics
High Surge Power (8000VA) – Easily handles motor-based and heavy appliances
Wide Input Voltage Range – Optimized for both personal computers and home appliances
Fast Transfer Time – Seamless switching (10ms for PCs, 20ms for appliances)
High Charging Capability – Up to 120A solar and 100A AC charging current
Smart Battery Management – 24V battery system with overcharge protection
WiFi & Multiple Communication Ports – USB, RS232, RS485, WiFi & dry contact support
Durable & Compact Design – IP21 protection with lightweight 10kg build
| Parameter | Specification |
|---|---|
| Voltage | 230 VAC |
| Selectable Voltage Range | 170–280 VAC (Personal Computers); 90–280 VAC (Home Appliances) |
| Frequency Range | 50 Hz / 60 Hz (Auto Sensing) |
| AC Voltage Regulation (Battery Mode) | 230 VAC ± 10% |
| Surge Power | 8000 VA |
| Efficiency (Peak) | 90% – 93% |
| Transfer Time | 10 ms (Personal Computers); 20 ms (Home Appliances) |
| Waveform | Pure Sine Wave |
| Battery Voltage | 24 VDC |
| Floating Charge Voltage | 27 VDC |
| Overcharge Protection | 33 VDC |
| Solar Charger Type | MPPT |
| Maximum PV Array Power | 5600 W |
| MPP Range @ Operating Voltage | 60 – 450 VDC |
| Maximum PV Array Open Circuit Voltage | 500 VDC |
| Maximum PV Input Current | 40 A |
| Maximum Solar Charge Current | 120 A |
| Maximum AC Charge Current | 100 A |
| Maximum Charge Current | 120 A |
| Dimensions (D × W × H) | 136 × 300 × 400.2 mm |
| Net Weight | 10 kg |
| Communication Interface | USB / RS232 / RS485 / WiFi / Dry Contact |
| Operating Humidity | 5% – 95% RH (Non-condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
| Ingress Protection | IP21 |
