Description
With a wide current measuring range up to 100A and high accuracy of 1%, this digital meter ensures dependable performance for power distribution, automation, and control applications. The fast response speed of 2 readings per second enables real-time data tracking, while the compact DIN-rail installation allows easy integration into standard electrical cabinets.
Key Features
Multifunction Power Monitoring – Measures current, power, energy, frequency, and power factor in one device.
Wide AC Current Range (0–100A) – Suitable for residential, commercial, and industrial electrical systems.
High Measurement Accuracy – Provides reliable readings with 1% ±2 words precision.
Real-Time Fast Response – Updates measurements twice per second for accurate monitoring.
Energy Consumption Tracking – Records electric energy usage up to 99,999 kWh.
Power Factor Measurement – Helps analyze load efficiency and power quality.
Wide Frequency Range – Supports 45Hz to 65Hz for stable operation.
DIN-Rail Mounting Design – Ensures quick, safe, and space-saving installation.
| Specification | Details |
|---|---|
| Model | YD-52 2066 |
| Current Range | AC 0–100.0A (Resolution: 0.01A) |
| Frequency Range | 45.0Hz – 65.0Hz |
| Power Factor | 0.00 – 1.00 PF |
| Electric Power | Up to 45,000 W |
| Electric Energy | 0 – 99,999 kWh |
| Accuracy | 1% ±2 words |
| Display Update Speed | 2 times per second |
| Installation Type | DIN-Rail |
