CNC YCISC8-32XPV PV ARRAY DC Isolator-Cage Type Isolation Switch

Description

CNC YCISC8-32XPV PV ARRAY DC Isolator

The YCISC8 Series Cage Type Isolation Switch is a high-performance switch designed for DC power systems with a rated voltage of DC1200V or below and a rated current of up to 32A. This switch is ideal for infrequent on/off operations and can simultaneously disconnect 1–2 MPPT lines. Its primary applications include use in control cabinets, distribution boxes, and combiner boxes within photovoltaic power generation systems, providing effective isolation for DC power distribution. Built with robust waterproofing and durable materials, it ensures reliable performance in demanding environments.

Key Features

• Superior Waterproofing: External installation type “E” achieves IP66 waterproofing at any angle, ensuring reliability in outdoor environments.
• UV and Flame Resistance: Constructed with UV-resistant, V0 flame-retardant materials for enhanced durability and safety.
• High-Quality Contacts: Features silver-plated contacts with industry-leading silver layer thickness, ensuring excellent conductivity and durability.
• Rapid Arc Extinguishing: Efficient arc extinguishing with a time of just 3ms for enhanced safety during operation.
• Breather Valve: Equipped with a breather valve at the bottom of the external box to maintain pressure balance and prevent condensation.
• Nonpolarity Design: Simplifies installation and usage with a nonpolar configuration.
• Lockable for Safety: Can be securely locked in the closed position to prevent accidental operation.
• Flexible Installation: Offers four installation modes to adapt to various setups and requirements.

Technical Specifications

• Rated Voltage: DC1200V and below
• Rated Current: 32A and below
• Waterproof Rating: IP66
• Arc Extinguishing Time: 3ms
• Standards Compliance: IEC/EN60947-3, AS60947.3, UL508i

The YCISC8 Series Cage Type Isolation Switch is a dependable and versatile solution for isolating DC power distribution systems in photovoltaic installations. Its advanced features, durable construction, and adherence to international standards make it a top choice for ensuring safety and performance in solar power systems.
